1.采用集成电路，IGBT逆变电源技术，使用普通氩弧焊枪实现等离子焊接效果

2.电弧通过电磁强化，形成类似等离子弧的电弧，电弧的稳定性，发热量，温度等相比普通氩弧焊有很大提高。具有较大的熔透力和较高的焊接速度

3.使用高频振荡作用于熔池，提高熔池的流动性，有效提高焊缝抗裂等力学性能。

4.具有焊道收缩功能，焊缝成形窄，光洁度高，易打磨

5.适用于所有氩弧焊及部分等离子弧焊接工艺所要求的焊接场合

6.主要应用于管道焊接.

1、Adapt integrated circuit and IGBT inverter power source technology, use argon torch to achieve the effect of plasma welding.

2、A similar plasma arc is formed through the electromagnetic reinforcement, The arc’s stability, heating release, and temperature are greatly improved comparing with traditional arc welding .It has a better penetration and higher welding speed.

3、Use the high-frequency oscillation in the molten pool to improve the liquidity of the molten pool, and effectively improve the crack resistance.

4、Reliable in producing deep and narrow, high smooth and easily polished welding beams.

5、Suitable for occasions of arc welding and some parts of plasma welding.

6、Mainly used in pipe welding.
